The X3-SUB is a rugged, self-powered remote data logger system specifically designed for offshore use without fear of accidental flooding. It automatically recognizes sensors and sends data to the WQData LIVE web data center via cellular or satellite telemetry. There, data is presented on a fully-featured and easy-to-use dashboard where remote, real-time communication with the […]
Configuring an environmental data logger has traditionally been a complex task requiring intricate programming software. Users were tasked with indicating all connected sensors’ communication protocols, sensor addresses, measurement commands, data format, and power requirements. However, with NexSens X3 data loggers, this process is simplified through sensor detection. Using a built-in sensor library, X3 data loggers […]
The X3 is an all-in-one environmental data logger designed for both pole/wall mount and buoy-based applications. It automatically recognizes sensors and sends data to the WQData LIVE web data center via cellular or satellite telemetry. There, data is presented on a fully-featured and easy-to-use dashboard where remote, real-time communication with the logger is possible. The […]
The X2 is an all-in-one environmental data logger that can be controlled from any internet browser using a smartphone, tablet, or PC. It automatically recognizes sensors and sends data to the WQData LIVE web data center via Wi-Fi, cellular, radio, or satellite telemetry. There, data is presented on a fully-featured and easy-to-use dashboard where remote, […]
The schematics and table below detail the 6-pin plug and receptacle (UW-6) universal pinout for all 6-pin NexSens cables excluding the 6-pin AC adapter. Universal Pinout Note: For instruments shown below, all signals in the table refer to their 6-pin receptacle port. Plug Pin Receptacle Pin Wire Color G2-Series Signal […]
Each X2 data logger has a body tag number etched into the side of the bottom bulkhead. It is located on the lower backside of the logger in between the two RF ports or plugs. The body tag number is incorporated into the default name of the device on WQData LIVE and will […]
The X2 offers several power input options for flexibility in system design and redundancy in critical monitoring applications. Available options include solar-charged power pack, battery-only and AC power. Basic Requirements Supply Voltage: 5-24VDC [+/-15%] (Reverse polarity protected) Current Draw (Typical @ 12VDC): Low power sleep: 350uA; Logger Active: 35mA; Wi-Fi Transmitting: 43mA; Cellular Transmitting: […]
The X2 contains two sets of (4) LEDs visible through the lid of the enclosure. These X2 LED indicator lights give insight into the operation of the data logger and Wi-Fi module, respectively. Two additional green LEDs beneath each magnet port give feedback when the magnet input is triggered. Note that all LED operation is […]
