Relative humidity is a measure of the moisture content of air relative to the maximum amount of moisture the air can hold at a given temperature. It is expressed as a percentage, where 100% relative humidity indicates that the air is fully saturated with moisture and cannot hold any more at its current temperature and pressure. Such conditions produce the possibility of precipitation, dew, or fog.
An instrument for measuring humidity is commonly called a hygrometer. Since relative humidity is temperature-dependent, hygrometers are frequently equipped with an air temperature sensor as well.
Why Measure Relative Humidity?
Relative humidity is a crucial parameter in meteorology and environmental monitoring due to its significant impacts on weather, human comfort, and various environmental processes. It is also interrelated with several other meteorological parameters such as dew point, heat index, and wind chill.
Some of the use cases for humidity measurement include:
- Weather Forecasting: High relative humidity levels are indicative of conditions that can lead to cloud formation and precipitation. Meteorologists use humidity data to predict rain, snow, and storm systems.
- Meteorological Observation: Besides the relation to clouds and precipitation, high humidity near the ground can lead to fog and dew formation, affecting visibility and surface conditions. Other humidity-related meteorological observations include:
- Dew point is the temperature at which moisture in air with 100% relative humidity must come out of the atmosphere in the liquid form.
- Relative humidity, in combination with air temperature, is used to calculate the heat index, which indicates how hot it feels to humans.
- Wind chill index has a region-dependent definition/calculation but assesses how the human body actually feels temperature by taking into account wind speeds and humidity.
- Health and Comfort: As the heat index indicates, high humidity conditions can make temperatures feel much hotter and lead to the potential for heat-related illnesses. Extremely high or low humidity levels can also affect respiratory health, aggravate allergies, and influence the spread of airborne diseases.
- Agriculture: Humidity levels affect plant transpiration and can influence the health and yield of crops. Certain pests and diseases thrive under specific humidity conditions, making it important for agricultural planning.
- Building and Materials: High humidity can lead to condensation and moisture buildup in buildings, which can cause mold growth and structural damage. Maintaining optimal indoor humidity levels is important for comfort and preventing damage to furniture and electronics.
How Is Relative Humidity Measured?
Hygrometers are scientific instruments used to measure humidity. There are several types of hygrometers, including mechanical, capacitive, resistive, dew point, and optical.
Mechanical hygrometers use organic materials such as human hair or animal gut that are highly sensitive to humidity changes, expanding and contracting with changes in humidity. These changes move a needle on a dial to indicate the humidity level.
Mechanical hygrometers represented an early advancement in humidity measurement, but integration into real-time measurement systems requires an output that can be read by a data logger. For this, electrical hygrometers that can output an analog or digital signal are used.
Many electrical humidity sensors for environmental monitoring are based on capacitive technology, similar to the measurement principle of capacitive barometers. Capacitive hygrometers typically use a thin film of hygroscopic (moisture-retaining) material between two conductive plates whose dielectric constant changes with the humidity, altering the capacitance.
Capacitive hygrometers use a layer of moisture-retaining material between two capacitive plates to detect changes in humidity levels.
An air temperature measurement taken alongside the capacitive humidity sensor allows for determination of the relative humidity. Using the temperature and relative humidity, the dew point temperature at which water will begin to condense can also be calculated from a formula.
Resistive hygrometers function similarly but measure changes in the electrical resistance rather than capacitance of a hygroscopic material. However, these are not used as commonly as capacitive sensors.
Dew point hygrometers are specialized instruments that provide a direct measurement of dew point by, for example, cooling a surface within the sensor and observing when moisture begins to condense. By knowing the air temperature and dew point temperature, the relative humidity can be calculated.
Dew point hygrometers can achieve high accuracy and are suitable for meteorological stations and research applications where accuracy is paramount. However, they are relatively complex compared to capacitive sensors, which are a cost-effective alternative suitable for many environmental monitoring applications.
Optical hygrometers measure humidity based on the absorption of specific wavelengths of light by water vapor in the air. They are precise and respond quickly, but they are more complex and costly than capacitive sensors, so they are less commonly used in general environmental monitoring applications.
How to Select a Relative Humidity Sensor?
When selecting a relative humidity sensor, consider the physical configuration, accuracy, operating range, power consumption, response time, and long-term stability.
Humidity sensors include temperature measurement for relative humidity calculation. Some are integrated into multi-parameter instruments, while others are dedicated instruments for temperature and humidity only.
Multi-parameter instruments offer convenience of mounting and integration, but dedicated sensors may offer advantages such as improved accuracy or flexibility of placement at a specific height or location.
Required accuracy is normally dictated by the application. Measurement stations adhering to meteorological standards or for climate research may require high-accuracy instrumentation, while systems intended for applications like agriculture, indoor air quality management, or general meteorological observation may only require accuracy within a few percentage points.
The measurement range of most sensors will be the full scale from 0-100% humidity. However, ensure that the sensor can operate effectively in the expected humidity and temperature ranges of the application environment. Sites experiencing extreme low or high temperatures may require a specialized hygrometer.
Power consumption is important for remote systems that will operate from solar-charged batteries or other similar autonomous power supply. Sensor response time becomes important in situations where the sensor will be switched on and off to conserve power between measurement intervals, or in dynamic environments where the humidity can change rapidly.
Lastly, for systems intended for long-term measurement especially in remote, unattended locations, consider the long-term stability of the sensor. Minimal drift is important for maintaining accurate measurements over time.
What to Consider When Preparing a Relative Humidity Sensor?
Much like barometric pressure measurement, calibration, ventilation, and mounting are crucial to acquire high-quality humidity data. Sensors are generally supplied with a factory calibration. User calibration may be possible with some devices. Become familiar with any applicable calibration procedures prior to installation.
Proper ventilation is also critical for measurement accuracy. Ensure adequate airflow around the sensor to provide representative measurements of the ambient air. Many sensors have a built-in radiation shield or other accessory that prevents measurement error from direct sunlight.
How to Deploy a Relative Humidity Measurement System?
As with other meteorological parameters, obtaining quality relative humidity data depends heavily on site selection and proper mounting.
Sensors must be placed where they can obtain representative readings. Guidelines will often specify mounting heights above the ground to avoid potential measurement error from ground-level moisture, including dew and fog.
Consider the mounting height of humidity sensors to ensure representative measurements.
Sensor placement should also be chosen to avoid interference from large objects like trees, buildings, or solar arrays. For multi-parameter instruments, a balance must be found to obtain accurate, representative values for each of the different sensors integrated. A dedicated instrument offers more flexibility in mounting.
For humidity measurement related to building automation or indoor environments, sensors should be placed clear of any exhaust vents, electrical machinery, or water supplies.
Conclusion
Relative humidity measurement is a vital component of meteorological and environmental monitoring. It is an important parameter on its own for applications such as weather forecasting and agricultural planning, but it is also important for its relation to other parameters such as dew point, wind chill, and heat index.
When combined with barometric pressure measurement (and air temperature), some advanced meteorological parameters such as absolute humidity, mixing ratio, and vapor pressure can also be calculated. Regardless of whether measurements are used for advanced metrics, relative humidity comprises a fundamental pillar in meteorology.
