NexSens High Gain 900 MHz Radio Antenna

The A44 high gain radio antenna is an excellent choice for remote communication via spread spectrum radio at distances up to 1 mile.

Features

  • Includes antenna and mounting bracket for simple installation in minutes
  • High performance whipless design is perfect for field deployments
  • Employs an N-style female RF connector for use with standard RF cables

Details

The A44 high gain antenna features a 902-928 MHz frequency range, weatherproof ABS housing, 3 dBi nominal gain, and an N-style connector for quick connection to NexSens RF cables.

This low-profile antenna is 2.30" tall and extremely rugged for commercial applications. The chrome bushing with o-ring ensures a durable seal to allow for long term deployments in harsh environments.

This high gain antenna receives and transmits in any direction, making it the preferred antenna for most short range (up to 1 mile line-of-sight) spread spectrum radio applications.

Parts


ImagePart#Product DescriptionQuote
A44A44High gain 900 MHz radio antenna, Type N female connectorquick_quote
